Determine Optimal Store Locations using White Space Analysis

Summary

How do you determine where to open a new retail location? Discover how to use White Space Analysis & Spatial Data to make more informed decisions.

This post may describe functionality for an old version of CARTO. Find out about the latest and cloud-native version here.
Determine Optimal Store Locations using White Space Analysis

As brick & mortar retailers  and the CPG categories they distribute  look to expand their footprint  network planners need access to insightful analysis and modeling techniques to drive better decisioning. After all  opening a new location is often the single largest cost retailers have to bear. In this post  we outline how spatial data and white space analysis can be used to surface the most viable new store sites.

Our Analytics Toolbox for BigQuery  a set of User Defined Functions for running advanced spatial analytics natively in BigQuery  has been further enhanced with a new set of retail-specific functions including revenue prediction and white space analysis.

White space analysis solves the ultimate question in retail expansion: where should I open my next store? The output of the analysis are the best potential locations  understood as those where the expected revenue is higher and where other business criteria are also met: e.g.  the presence or absence of existing stores and/or competitors.

In order to complete end-to-end white space analysis  three steps are necessary  each  corresponding to a specific procedure in the CARTO’s Analytics Toolbox for BigQuery: data preparation  model training  and locating whitespace areas  running the BUILD_REVENUE_MODEL_DATA  BUILD_REVENUE_MODEL  and FIND_WHITESPACE_AREAS procedures  respectively.

To showcase the usage of the white space analysis we will build on the same revenue prediction use-case of our previous blogpost. We are going to use a set of liquor store locations under the brand Hy-Vee and their associated annual revenue for 2019  extracted from the publicly available Iowa Liquor Sales datasets. All other liquor stores will be considered Hy-Vee's competitors.

In this particular example we are using an H3 grid at resolution 7 and the same set of enrichment variables we used in the previous blog post: total population and number of POIs for  different categories  in particular  retail  financial  food & drinks  leisure  transportation and tourism  extracted from CARTO's Spatial Features dataset available via our Data Observatory.

Data preparation

This step has the objective of enriching the area of interest where the analysis will be performed using both the data provided by the retailer (existing store locations and their revenue  and competitor locations)  and data from the Data Observatory subscription detailed above .

The following SQL operation is performed using the BUILD_REVENUE_MODEL_DATA procedure:

CALL `carto-un`.carto.BUILD_REVENUE_MODEL_DATA(
   -- Stores: revenue  store  geom
   '''
   SELECT store_name as store ST_GEOGFROMTEXT(any_value(store_location)) as geom  sum(sale_dollars) as revenue FROM
  `bigquery-public-data.iowa_liquor_sales.sales`
   where store_name like "%Hy-Vee%" and EXTRACT(YEAR FROM date)=2019
   group by store_name
   '''
   -- Competitors: competitor  geom
   '''
   SELECT store_name as competitor ST_GEOGFROMTEXT(any_value(store_location)) as geom FROM
  `bigquery-public-data.iowa_liquor_sales.sales`
   where store_name not like "%Hy-Vee%" and EXTRACT(YEAR FROM date)=2019
   group by store_name
   '''
   -- Area of interest: geom
   '''
   SELECT state_geom AS geom
   FROM `bigquery-public-data.geo_us_boundaries.states`
   WHERE state_name='Iowa'

   '''
   -- Grid params: grid type and level
   'h3'  7
   -- Decay params: kring size and decay function
   1  ''
   -- Data Observatory enrichment
   [("population_f5b8d177"  'sum')  ("retail_21cb1815"  'sum') ("financial_9b8bb507" 'sum') ("food_drink_bd2ef444" 'sum') ("leisure_16da1bd6" 'sum')
   ("transportation_63a2617a" 'sum') ("tourism_fc201498" 'sum')]
   '<my-dataobs-project>.<my-dataobs-dataset>'
   -- Custom data enrichment
   NULL  NULL
   -- Output destination prefix
   'cartobq.docs.whitespace_analysis_iowa'
);

The result is a table (cartobq.docs.whitespace_analysis_iowa_model_data) including one row for every H3 grid cell at resolution 7; each containing their associated enrichment values  including the number of stores  competitors and the variables coming from CARTO’s Spatial Features dataset specified earlier.

Model training

This step builds the revenue prediction model using the data resulting from the data preparation step. The model is trained using BigQuery ML’s Boosted Tree Regressor  which the user can tweak using the options parameter of the BUILD_REVENUE_MODEL procedure.

The following SQL operation is performed:

CALL `carto-un`.carto.BUILD_REVENUE_MODEL(
   -- Model data
   'cartobq.docs.revenue_prediction_iowa_whitespace_analysis_data'
   -- Options
   '{"MAX_ITERATIONS": 20  "MAX_TREE_DEPTH":3}'
   -- Output destination prefix
   'cartobq.docs.whitespace_analysis_iowa
'
);

Finding whitespace areas

Once we have enriched our area of interest using the chosen spatial resolution and trained our revenue prediction model  the last step consists in finding the locations within our area of interest where a new store would perform best. For that purpose  we are going to use the FIND_WHITESPACE_AREAS procedure  which takes the following parameters as input:

  • Table containing the enriched dataset of our area of interest (result from running the BUILD_REVENUE_MODEL_DATA).
  • Revenue prediction model (result from running BUILD_REVENUE_MODEL).
  • Optional spatial filter to reduce the search area.
  • Optional minimum amount of revenue and maximum number of results.
  • Two flags indicating whether to include in the search those cells where competitors and/or the retailer’s own stores are present.
  • Collection of locations (generators) around which the search will be performed. Since the algorithm will look for whitespaces only in the surroundings of these locations  it will avoid offering results that are not of interest to the user. For instance  these could be the locations of existing stores  their competitors  or a collection of POIs that are known to drive commercial activity to an area.

For our particular analysis  a good choice for the generator locations is the set of transportation  retail and food & drink POIs  as those are the ones with the highest feature importance in our revenue prediction model (see table below). The location of these POIs has been extracted from the OpenStreetMap planet nodes dataset and those for Iowa have been stored in the table cartobq.docs.whitespace_analysis_iowa_generator_pois.

Table showing attributions of feature names


We can use this procedure to run a preliminary exploration to visualize all areas with a minimum amount of potential revenue  in this case $200 000. The result has been stored in the table whitespace_analysis_iowa_result_allcells_min2e5.

CALL `carto-un`.carto.FIND_WHITESPACE_AREAS(
  'cartobq.docs.whitespace_analysis_iowa_revenue_model'
  'cartobq.docs.whitespace_analysis_iowa_revenue_model_data'
  'SELECT * FROM cartobq.docs.whitespace_analysis_iowa_generator_pois'
  NULL  -- AOI query
  2e5  -- Minimum revenue
  NULL  -- Max results
  TRUE  -- Include cells with own stores
  TRUE -- Include cells with competitors
)

The following map displays the resulting whitespace areas  coloured by the amount of potential revenue  where darker colors represent higher values of revenue. The generator locations have also been included for reference in the visualization.

Then  we can rerun the procedure to find only the areas with the top 10 highest potential revenue where no previously existing stores or competitors are present.

CALL `carto-un`.carto.FIND_WHITESPACE_AREAS(
  'cartobq.docs.whitespace_analysis_iowa_revenue_model'
  'cartobq.docs.whitespace_analysis_iowa_revenue_model_data'
  'SELECT * FROM cartobq.docs.whitespace_analysis_iowa_generator_pois'
  NULL  -- AOI query
  2e5  -- Minimum revenue
  10  -- Max results
  FALSE  -- Include cells with own stores
  FALSE -- Include cells with competitors
)

The resulting white space areas are represented in red in the following map. Existing stores are displayed in blue  while competitors in yellow.

As we have seen in this post  white space analysis gives both retailers and CPG brands the flexibility to explore network expansion opportunities based on valuable spatial insights. This approach takes the guesswork out of site selection decisions  so businesses can hone in on those retail locations most likely to succeed.
These procedures are now available to CARTO users as part of the Analytics Toolbox for BigQuery. They can be run directly from the BigQuery console or from your SQL or Python Notebooks using the BigQuery client. Additionally  they will soon power the white space analysis engine integrated in CARTO's Site Selection application.
